Mitoitustaulukko
Kaikkien saatavilla olevien kokojen PTFE Coated Stainless Steel Threaded Bar - DIN 975 mitat on esitetty yllä olevan tuotepiirustuksen mukaisesti.
Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom right of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080
Instant Quote:
Submit a request for quote online by clicking the button below and a PDF quotation will be delivered to your inbox within 5 mins.
Materiaali: PTFE Coated
Measurement System: Metric
Blue
260°C
UL94 V0
PTFE Coated Stainless Steel Threaded Bar - DIN 975 on seuraavien standardien/normien mukainen:
DIN 975
PTFE Coated Stainless Steel Threaded Bars, available in sizes ranging from M5 to M30 with lengths between 25mm and 500mm. These high-performance threaded bars are manufactured from premium stainless steel and feature a PTFE (Polytetrafluoroethylene) coating that provides exceptional corrosion resistance, low friction, and enhanced durability. The PTFE coating not only offers superior protection against rust, chemicals, and environmental degradation but also delivers a smooth, non-stick surface that is easy to clean and maintain. Ideal for use in harsh environments, chemical processing, and industrial applications, these threaded bars ensure reliable performance and longevity.
Metric Size – M5, M6, M8, M10, M12, M14, M16, M20, M24, M30
Length (mm) – 25, 50, 75, 100, 150, 200, 300, 500
PTFE (Polytetrafluoroethylene) coated stainless steel merges the beneficial properties of both materials to form a versatile and highly functional composite. Here's a summary of its key properties:
Corrosion Resistance: Stainless steel's natural corrosion resistance, due to its chromium content, is further enhanced by the PTFE coating, providing superior protection against rust, chemicals, and environmental degradation.
Low Friction: PTFE's low coefficient of friction ensures smooth and easy movement. When applied to stainless steel, it reduces friction between surfaces, preventing wear and enhancing durability.
Chemical Inertness: PTFE is chemically inert and resists a wide range of chemicals. When coated onto stainless steel, it boosts the material's resistance to acids, bases, solvents, and corrosive substances.
Temperature Stability: PTFE maintains its properties over a broad temperature range (-200°C to +260°C). Combined with stainless steel, it enhances the material's ability to withstand extreme temperatures without losing integrity.
Non-Stick Properties: PTFE's excellent non-stick nature prevents substances from adhering to its surface, making it easy to clean and maintain when applied to stainless steel.
Electrical Insulation: PTFE is an effective electrical insulator, preventing electrical conductivity. Coating stainless steel with PTFE improves its electrical insulation properties.
Biocompatibility: PTFE is biocompatible and inert to biological tissues, making it suitable for medical and pharmaceutical applications. When applied to stainless steel, it enhances biocompatibility, reducing the risk of adverse reactions in biological systems.
What is a Threaded Bar?
A threaded bar, also known as a threaded rod or stud, is a long, cylindrical metal rod with threads along its entire length. These threads allow nuts or other threaded components to be attached at each end, providing a secure connection. Threaded bars are commonly used in construction, manufacturing, and DIY projects for applications such as fastening, bracing, anchoring, and suspension. They come in various materials, diameters, and thread sizes to suit different requirements and can be cut to custom lengths as needed.
PTFE Coated -tiedote on ladattavissa PDF-tiedostona alla.
Palauta komponentit 90 päivän kuluessa ja saat täyden hyvityksen. Katso lisätietoja palautusehdoista.
Size | M5 | M6 | M8 | M10 | M12 | M16 | M20 | M24 | M30 |
Kaikkien saatavilla olevien kokojen PTFE Coated Stainless Steel Threaded Bar - DIN 975 mitat on esitetty yllä olevan tuotepiirustuksen mukaisesti.
